Curved LED Screen 500×500 Flexible Curved Rental LED Display Series

LM500H5 cabinet adopts ultra-thin design, removable back cover,
LED corner protector, magnetic module, high waterproof.

500H5-1

Front and Rear Service Design

LM500H5 series Curved LED display Module adopts Magnet Adsorption LED Panel to make the cabinet is accessed with frontal & rear design. Easy installation for LED panels.

500H5-2

Perfect Cabinet Design

Excellent product came in all details from cabinet handle. cabinet fxied slot, fast lock,
magnet adsorption module, module installation knob, Power& signal connector, detachable power boxing, and more

500H5-3

Detachable Power Box

Full front maintenance operation, the power box can be removed from the front of the cabinet.

500H5-4

Quick Install

LM500H5 Series LED screen Two Fast Locks on Left and Right Side,Ensure faster assembly and better screen flatness.

500H5-5

Corner Protector

The LED screen has four corners to prevent damage to the LED,Transportation, installation, operation,
disassembly and assembly are more secure and easy to use.

500H5-6

Lightweight and Thin

LM500H5 series LED display cabinet weighs 7KG/pc, easy to operate: one person to install, disassemble and maintain.

500H5-7

IP65 Dustproof And Waterproof

LM500H5 series outdoor LED display supports IP65 dustproof and waterproof,
it can resists severe weather conditions during outdoor activities.And die-cast aluminum is corrosion resistant.

500H5-8

Wide Viewing Angle

Viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle.
Ultra-wide viewing angle give you the largest screen viewing area. It offers you clear and natural images in all directions.

500H5-9

Outdoor Indoor Curved LED Screen Rental 500x500 Series Parameter

Pixel Pitch (mm)P3.91P4.81
ModelLM500H5-OP3.91LM500H5-OP4.81
Pixel ConfigurationSMD1921SMD1921
Density (Pixels/㎡)65,53643,264
Module Resolution (Pixel)64x6452x52
Module Size (mm)250x250250x250
Driving Mode (Duty)1/16 1/13
Cabinet Size (mm)500x500500x500
Cabinet Weight (KG)77
Brightness (CD/㎡)≥6,000≥6,000
Viewing Angle (°)140140
Gray Grade (Bits)1414
Operation PowerAC100-240V 50-60HzAC100-240V 50-60Hz
Max. Power Consumption (W/㎡)720560
Avg. Power Consumption (W/㎡)240190
Frame Frequency (Hz)≥60≥60
Refresh Frequency (Hz)≥3,840≥3,840
Working Temperature (ºC)-20～+60-20～+60
Lifetime (Hours)100,000100,000
Protection GradeIP65(front), IP54(rear)IP65(front), IP54(rear)

Indoor 500x500mm Rental Curved LED Display 500x500 Series Parameter

Pixel Pitch (mm)P2.6P2.97P3.91
ModelLM500H5-iP2.6LM500H5-iP2.97LM500H5-iP3.91
Pixel ConfigurationSMD1515SMD2121SMD2020
Density (Pixels/㎡)147,928112,89665,536
Module Resolution (Pixel)96x9684x8464x64
Module Size (mm)250x250250x250250x250
Driving Mode (Duty) 1/32 1/281/16
Cabinet Size (mm)500x500500x500500x500
Cabinet Weight (KG)6.56.56.5
Brightness (CD/㎡)≥1200≥1,000≥1,200
Viewing Angle (°)140140140
Gray Grade (Bits)141414
Operation PowerAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60Hz
Max. Power Consumption (W/㎡)480480576
Avg. Power Consumption (W/㎡)160160192
Frame Frequency (Hz) ≥60≥60≥60
Refresh Frequency (Hz) ≥3,840≥3,840≥3,840
Working Temperature (ºC)-20～+60-20～+60-20～+60
Lifetime (Hours)100,000100,000100,000
Protection GradeIP31IP31IP31
LeemanLED has more than 25 years of experience manufacturing Fixed LED Displays & Rental LED Screens for INDOOR and OUTDOOR purposes.
Due to the modular system, our LED Video Wall Screens can adapt to many applications: Churches, Retail, Education, Rental Companies, Events, TV Studios, AVP, and many other visual experiences.
